Model NEO α Alpha
Feature overview
XMOS 216+ESS9038Pro DAC hardware decoding, DSD512/PCM768KHz 32bit and MQA.
Dual HDMI audio and video separation output, multi-channel DSD playback (2.0/5.1CH) and DSD native output.
430 standard dimensions, excellent texture with reinforced aluminum alloy cabinet and shockproof foot pad.
5-inch OLED high-definition touchscreen displays general settings, music playback status and touch controls.
RTD1619DR SOC with 4K@60Hz, Dolby Vision/HDR10+.
4G DDR4 RAM and 32G eMMC storage；512G SSD for local media storage.
Internal 3.5"/2.5" hard drive bay, up to 18T large capacity hard drive (hard drive not included).
Two power supplies, linear power supply and digital power supply.
4K 60Hz, HDR (HDR10/HLG/HDR10+/Dolby Vision), 12bit, BT.2020 Wide Color Range and YCbCr 4:4:4.
Supports DSD (SACD ISO, DSF, DFF), WAV, FLAC, APE lossless audio formats and seamless multi-sampling playback.
Powerful Bluetooth decoding with Qualcomm's flagship QCC5125 module, support APTX HD, LDAC audio reception.
6.35 headphone jack, two gain modes switchable, internal headphone amplifier can drive 16-300 Ω high impedance headphones.
Multi-stage operational amplifier, fully balanced circuit design, XLR balanced and RCA output.
Support asynchronous USB DAC input, monitor level sound card performance, compatible with Windows, MAC, IOS, Android.
XMOS XU216, MQA full decoding and dual active femtosecond crystal oscillator.
Rigorous circuit design, manufacturing process and selected components.
Based on Linux video decoding and output framework to output high reproduction image quality.
Supports almost all Dolby Vision formats and full processing for stunning picture quality.
VS10 engine supports content mapping and colors similar to Dolby Vision, image quality is greatly improved.
Posterboard management system supports automatic intelligent scanning, custom classification and movie information management.
Gigabit cable network and 2.4G+5G dual-band 802.11 AC 2T2R 867Mbps WiFi.
CD-ROM playback and CD ripping are supported. It can be connected with BD (not encrypted)/CD discs.
New Music Player supports personalized configuration, lyrics and track data matching.
Supports AirPlay, DLNA, Spotify and Roon Ready streaming services, etc.
Supports optical and coaxial audio input and bit-perfect digital audio output via USB Audio Native, Optical and HDMI.
Supports multiple network protocols such as NFS, SMB v1/v2/v3,
UPnP and Web DAV.
SMB sharing allows transfer of local media files
stored on the Zidoo hard drive to other devices.
Specifications:
Display: 5-inch OLED HD touchscreen
Housing: aerospace aluminum alloy
CPU: Realtek RTD1619DR ARM Cortex-A55(Hexa-Core)
GPU: ARM Mali-G51 MP3
DAC: ESS 9038Pro
Audio Processor: XMOS XU216
Internal SSD: 512G SSD (M.2 SATA 3.0 2280 interface protocol, up to 1TB)
SATA Internal: SATA3.0 hard drive bay*1 (supports 2.5/3.5 inch hard drives, hard drives are not included)
Wi-Fi: 2.4G+5G dual-band WiFi, 802.11 a/b/g/n/AC 2T2R MIMO 867Mbps
Ethernet: RJ-45(10/100/1000Mbps)
HDMI: Main output HDMI 2.0a supports 4K@60fps/12Bit/HDR/BT2020/YCbCr 4:4:4 video output
Supports audio passthrough
HDMI: DSD audio output HDMI 1.4
Music: supports DSD 64 2CH/5.1CH(DSD Native)
Movie: supports audio passthrough
Video decoding: 4K@60p HEVC/H.265 12bit HDR10, HDR10+, Dolby Vision
Audio decoding: support True HD HD audio passthrough, stereo PCM decoding.
DAC audio decoding: support DSD512 in stereo, PCM 768KHz 32bit, MQA.
Bluetooth audio input: Qualcomm QCC5125 Bluetooth module (BT5.0)
Supports audio protocols like: SBC/AAC/aptX/aptX LL/aptX HD/LDAC
USB audio input: USB audio compatible system: Windows（7，10）Mac, Android, iOS.
Supports up to stereo DSD512, PCM 768KHz 32bit, MQA.
Digital audio input: USB DAC input, coaxial input, optical input, Bluetooth audio input
Digital audio output: optical output, HDMI output, USB audio output, Bluetooth audio output
Analog audio output :Preamp output: XLR (balanced), RCA
Headphone amplifier output: 6.35mm single-ended
USB: 2xUSB3.0，2xUSB2.0
Control Methods: Remote control, Mobile APP control, Touch screen control, TCP/IP control（WOL), RS232 serial port control, IR IN port control.
Headphone impedance 16-300Ω (low gain mode: 16-32Ω/high gain mode: 32-300Ω).
XLR (balanced) output Output level (Vrms): 4.3 Vrms
THD+N: -115dB（0.000167%@1kHz）
Noise: less than 2uVrms
SNR: 127dB@1kHz
Frequency Response: ±0.25dB(20Hz-20kHz)
CROSSTALK: -130dB@1kHz
DNR: 127dB@1kHz
RCA output (single-ended) Output
